High brightness 480*800 SPI+RGB interface IPS 4.3 inch Tft Display
Product Introduction
Introduction to Ruixiang’s cutting-edge TFT display
Ruixiang is proud to introduce our latest innovation in display technology - TFT display. Our TFT displays are available in two options, a 4.3-inch touch display with 480*272 and 800*480 resolutions, designed to provide superior visual performance and versatility. Whether you are looking for standard products or customized solutions, Ruixiang can meet your needs.
Our TFT displays are equipped with advanced touch screen capabilities, offering both capacitive and resistive touch screen options. This ensures our customers have the flexibility to choose the touch technology that best suits their specific requirements. Whether it's consumer electronics, industrial applications, automotive displays or any other use case, our TFT displays are engineered to deliver outstanding performance and reliability.
The main features of Ruixiang TFT display:
1. High-resolution visual effects: Our TFT display has high resolutions of 480*272 and 800*480, ensuring clear visual effects and an immersive viewing experience.
2. Touch screen options: Customers can choose between capacitive and resistive touch screens, providing flexibility and customization to meet different application needs.
3. Customization capabilities: In addition to our standard products, Ruixiang also provides customization options, allowing customers to customize TFT displays according to their specific requirements.
4. Wide range of applications: From handheld devices to industrial equipment, automotive displays, etc., our TFT displays are suitable for a wide range of applications.
5. Excellent quality: Ruixiang's TFT displays are manufactured with quality and durability in mind, ensuring long-term reliability and performance.
Why choose Ruixiang TFT display?
Ruixiang is committed to providing cutting-edge display solutions to meet the ever-changing needs of customers. Our TFT displays are the result of extensive research, development and engineering expertise, ensuring they meet the highest quality and performance standards.
By offering both standard products and custom options, we enable our customers to find the perfect display solution for their unique needs. Whether it's a specific size, resolution, touch technology or other customization, Ruixiang's TFT displays can be tailored to meet your exact specifications.
In addition, our TFT displays are designed to be user-friendly and provide an intuitive touch interface, enhancing the overall user experience. Whether you're browsing menus, interacting with apps, or entering commands, our touchscreens are responsive and accurate.
Additionally, our commitment to quality means our TFT displays undergo rigorous testing and quality control measures to ensure they meet the highest standards. Customers can be confident in the reliability and longevity of our display solutions, making them a sound investment for their applications.
Choose Ruixiang's TFT display for unparalleled performance
When selecting TFT displays for your application, Ruixiang stands out as a trusted partner, offering superior quality, performance and customization options. With our range of TFT displays, customers can expect excellent visual clarity, responsive touch interfaces and versatile solutions for different application needs.
Whether you are in consumer electronics, industrial, automotive or any other industry that requires high-quality display solutions, Ruixiang's TFT displays are the ideal choice. Contact us today to learn more about our TFT displays and how they can take your products and applications to the next level.
Our Services
Ruixiang(RX) provides customers with flexible customization services: customized screen FPC, screen IC, screen backlight, touch screen cover plate, sensor, touch screen FPC. For more details, please consult us, we will provide you with free project evaluation and project approval, and have a professional R & D personnel one-to-one project docking, welcome the demand of customers to find us!
E-mail: info@rxtplcd.com
Mobile/Whatsapp/WeChat: +86 18927346997
Website: https://www.rxtplcd.com
Product Specification
Ruixiang touch display technology Co., Ltd.
LCD Display Module
OEM/ODM customization is supported.
The following are not all sizes. If the size you need is not in the list, please tell us the size you need.
| Size (inch) |
Part No. | Resolution | LCD OD | View Area (mm) |
Interface | IC | FPC | Remark | |
| 2.4 | RXL024074-A | 240*320 | 42.72*58.9*2.2 | 36.72*48.96 | MCU(P) | ILI9341V | 40PIN | RTP/CTP | Contact US |
| RXL024091-A | 240*320 | 42.72*60.26*2.6 | 36.72*48.96 | MCU/SPI/RGB | ST7789V | 45PIN | RTP/CTP | ||
| RXL024102-A | 240*320 | 42.72*60.26*3.6 | 36.72*48.96 | MCU | ST7789V | 45PIN | RTP/CTP | ||
| RXL024102-A | 240*320 | 42.92*60.26*3.78 | 36.72*48.96 | MCU/SPI/RGB | ST7789V | 45PIN | IPS | ||
| 2.8 | RXL028052-A | 240*320 | 50.2*69.7*2.6 | 43.2*57.6 | MCU/SPI/RGB | ST7789V | 50PIN | RTP/CTP | |
| RXL028075-A | 240*320 | 50.5*69.7*2.6 | 43.2*57.6 | MCU/SPI/RGB | ST7789V | 50PIN | IPS | ||
| RXL028092-A | 240*320 | 50*69.2*2.45 | 43.2*57.6 | MCU(P) | ILI9341V | 37PIN | RTP/CTP | ||
| 3 | RXL030053-A | 240*400 | 45.4*77*2.6 | 39.24*65.4 | MCU/SPI/RGB | ILI9327 | 45PIN | IPS | Contact US |
| RXL030076-A | 240*400 | 45.4*77*2.6 | 38.88*64.8 | MCU/SPI/RGB | ILI9327 | 45PIN | RTP/CTP | ||
| 3.2 | RXL032054-A | 240*320 | 55.04*77.2*2.5 | 48.6*64.8 | MCU(P)/RGB | ILI9341 | 40PIN | RTP/CTP | |
| RXL032077-A | 240*320 | 55*77.2*2.6 | 48.6*64.8 | MCU/SPI/RGB | ST7789V | 50PIN | RTP/CTP | ||
| 3.5 | RXL035055-A | 320*240 | 76.9*63.9*3.25 | 70.08*52.56 | RGB | HX8238A | 54PIN | RTP/CTP | |
| RXL035093-A | 320*480 | 54.66*82.94*2.3 | 48.96*73.44 | MCU(P)/RGB | ILI9488 | 40PIN | RTP/CTP | ||
| RXL035103-A | 320*240 | 76.9*63.9*4.5 | 70.08*52.56 | RGB | HX8238A | 54PIN | RTP/CTP | ||
| RXL035109-A | 320*240 | 76.9*63.9*4.55 | 70.08*52.56 | RGB | HX8238A | 54PIN | IPS | ||
| RXL035113-A | 320*480 | 54.58*83.57*2.1 | 48.96*73.44 | MCU/SPI/RGB | ILI9488 | 50PIN | IPS | ||
| RXL035036-A | 320*480 | 55.5*84.9*2.5 | 48.96*73.44 | MIPI | ILI9488 | 20PIN | IPS | ||
| 4 | RXL040056-A | 480*800 | 79.38*76.43*2.8 | 70.176*71.856 | SPI/RGB | ST7701S | 50PIN | IPS | Contact US |
| RXL040078-A | 480*800 | 57.14*96.85*2 | 51.84*86.4 | MIPI | OTM8019A | 20PIN | IPS | ||
| RXL040094-A | 480*800 | 58.26*98.1*2.55 | 51.84*86.4 | SPI+RGB | ILI9806E | 50PIN | IPS | ||
| RXL040026-A | 480*800 | 57.15*96.85*2.3 | 51.84*86.4 | RGB | ILI9806 | 30PIN | IPS | ||
| RXL040104-A | 480*800 | 57.14*96.85*2 | 51.84*86.4 | MCU(P)/RGB | ILI9806G | 50PIN | RTP/CTP | ||
| 4.3 | RXL043057-A | 480*272 | 105.4*67.15*2.86 | 95.04*53.86 | 16/18/24RGB | ST7282 | 40PIN | RTP/CTP | |
| RXL043079-A | 480*800 | 62.5*105.55*2.5 | 56.16*93.6 | 16/18/24RGB | ILI9806E | 45PIN | IPS | ||
| RXL043095-A | 480*272 | 105.4*67.15*2.85 | 95.04*53.86 | 8/24RGB | SC7283 | 40PIN | Wide temp/IPS | ||
| RXL043105-A | 480*800 | 62.5*105.55*2.5 | 56.16*93.6 | MIPI | ILI9806E | 20PIN | IPS | ||
| RXL043119-A | 480*272 | 53.856*95.04 | 53.856*95.04 | RGB | HX8257-A00 | 40PIN | RTP/CTP | ||
| RXL043002-A | 480*272 | 53.856*95.04 | 53.856*95.04 | RGB | HX8257-A00 | 40PIN | RTP/CTP | ||
| 4.5 | RXL045058-A | 480*854 | 61.54*110.1*2.55 | 55.44*98.64 | SPI+RGB | ILI9806E | 45PIN | RTP/CTP | Contact US |
| RXL045080-A | 480*854 | 61.54*110.1*2.55 | 55.44*98.64 | MIPI | ILI9806E | 20PIN | IPS | ||
| 5 | RXL050059-A | 480*272 | 120.8*75.9*4.2 | 110.88*62.83 | RGB | HX8257-A00 | 40PIN | RTP/CTP | |
| RXL050081-A | 800*480 | 120.7*75.8*4.5 | 108*64.8 | RGB | ILI6122+ILI5960 | 40PIN | RTP/CTP | ||
| RXL050063-A | 800*480 | 120.7*75.8*4.3 | 108*64.8 | RGB | ILI6122+ILI5960 | 40PIN | RTP/CTP | ||
| RXL050020-A | 800*480 | 120.7*75.8*4.3.1 | 108*64.8 | RGB | ILI6122 | 40PIN | RTP/CTP | ||
| RXL050096-A | 800*480 | 120.9*78.1*2.95 | 108*64.8 | 16/18/24RGB | ST7262 | 40PIN | Wide temp/IPS | ||
| RXL050106-A | 720*1280 | 67.56*122.35*2.6 | 62.1*110.4 | MIPI | ILI9881C | 30PIN | IPS HD | ||
| RXL050025-A | 720*1280 | 65.4*119.3*1.64 | 62.1*110.4 | MIPI | / | 25PIN | |||
| RXL050110-A | 1080*1920 | 64.3*118.3*1.49 | 61.88*110.2 | MIPI | NT35596 | 39PIN | IPS HD | ||
| 5.5 | RXL055060-A | 720*1280 | 71.66*129.99*1.61 | 68.04*120.96 | MIPI | OTM1283A | 25PIN | IPS 1080P | |
| RXL055082-A | 720*1280 | 74.28*133.21*2.6 | 68.04*120.96 | 4 Lane MIPI | ILI9881C | 30PIN | RTP/CTP | Contact US |
|
| RXL055097-A | 1080*1920 | 74.28*133.21*2.6 | 68.04*120.96 | 4 Lane MIPI | NT35532 | 25PIN | IPS 1080P | ||
| 5.6 | RXL056061-A | 640*480 | 126.5*100*4.5 | 112.9*84.67 | 16/18RGB | / | 40PIN | RTP/CTP | |
| 7 | RXL070018-A | 800*480 | 165*100*3.5 | 154.08*85.92 | RGB | ILI6122+ILI5960 | 50PIN | RTP/CTP | |
| RXL070083-A | 800*480 | 165*100*5.7 | 154.08*85.92 | MIPI | ILI6122+ILI5960 | 50PIN | RTP/CTP | ||
| RXL070098-A | 800*480 | 165.4*104.59*5.8 | 152.4*91.44 | 16/18/24RGB | / | 40PIN | Wide temp/IPS | ||
| RXL070107-A | 1024*600 | 165*100*6 | 154.21*85.92 | RGB | NT52003+NT51008 | 50PIN | RTP/CTP | ||
| RXL070111-A | 1024*600 | 165*100*3.5 | 154.21*85.92 | MIPI | EK79007AD+ EK73215BCGA |
50PIN | RTP/CTP | ||
| RXL070114-A | 1024*600 | 164.9*100*3.5 | 154.21*85.92 | LVDS | 79001/EK73215BC | 30PIN | MVA | ||
| RXL070116-A | 1024*600 | 165*100*5.8 | 154.21*85.92 | 4 Lane MIPI | / | 30PIN | IPS | ||
| RXL070117-A | 800*1280 | 103.46*160.78*2.17 | 94.2*150.72 | MIPI | NT35521 | 40PIN | IPS | ||
| RXL070084-A | 800*1280 | 97.35*162.03*2.3 | 94.2*150.7 | MIPI | / | 40PIN | IPS | Contact US |
|
| RXL070029-A | 1200*1920 | 98.75*160.85 | 94.5*151.2 | MIPI | / | 40PIN | IPS | ||
| 8 | RXL080064-A | 800*600 | 183*141*5.6 | 162*121.5 | 24RGB | / | 50PIN | RTP/CTP | |
| RXL080050-A | 800*1280 | 114.6*184.1*2.5 | 107.64*172.22 | MIPI | / | 31PIN | IPS | ||
| RXL080120-A | 1024*768 | 136*174*2.5 | 162*121.5 | MIPI | 50PIN | RTP/CTP | |||
| RXL080049-A | 1024*768 | 183*141*6.3 | 162*121.54 | LVDS | 50PIN | RTP/CTP | |||
| 9 | RXL090065-A | 800*480 | 211.1*126.5*3.5 | 198*111.7 | 24RGB | / | 50PIN | RTP/CTP | |
| RXL090085-A | 1024*600 | 210.7*126.5*5 | 196.61*114.15 | RGB | / | 50PIN | RTP/CTP | ||
| 10.1 | RXL101086-A | 800*1280 | 143*228.6*2.8 | 135.36*216.57 | MIPI | / | 40PIN | IPS | |
| RXL101100-A | 1200*1920 | 143*228.7*2.2 | 135.36*216.58 | MIPI | / | 40PIN | IPS | ||
| RXL101073-A | 1080*1920 | 142.8*228.2 | 135.36*216.58 | MIPI | / | 40PIN | IPS | ||
| RXL101108-A | 1024*600 | 235*143*5.2 | 222.72*125.28 | LVDS | / | 40PIN | RTP/CTP | Contact US |
|
| RXL101112-A | 1024*600 | 235*143*5 | 222.72*125.28 | RGB | / | 30PIN | IPS | ||
| RXL101066-A | 1280*800 | 229.46*149.1*2.5 | 216.96*135.6 | LVDS | / | 40PIN | IPS | ||
| RXL101121-A | 1280*800 | 229.46*150.2*4.5 | 216.96*135.6 | LVDS | 40PIN | RTP/CTP | |||
| 10.4 | RXL104067-A | 800*600 | 228.4*175.4*5.9 | 211.2*158.4 | 24RGB | / | 60PIN | RTP/CTP | |
| 12.1 | RXL121068-A | 1024*768 | 279*209*9 | 245.76*184.32 | LVDS | / | 20PIN | RTP/CTP | |
| RXL121122-A | 1024*768 | 260.5*203.5*10 | 248*187 | LVDS | / | 20PIN | RTP/CTP | ||
| RXL121087-A | 1024*768 | 260.5*204*8.4 | 245.76*184.3 | LVDS | / | 30PIN | IPS | ||
| 13.3 | RXL133069-A | 1920*1080 | 306.3*177.7*5.4 | 293.47*165.07 | EDP | / | 30PIN | IPS | |
| RXL133088-A | 1920*1080 | 305.35*187.82*2.7 | 293.76*165.24 | EDP | / | 30PIN | IPS | ||
| RXL133101-A | 1920*1080 | 305.2*178.1*2.6 | 293.76*165.24 | EDP | / | 30PIN | IPS | ||
| 15.6 | RXL156070-A | 1920*1080 | 363.8*215.9*8.8 | 344.16*193.59 | EDP | / | 30PIN | 1000NITS | Contact US |
| RXL156089-A | 1920*1080 | 359.5*223.8*3.2 | 344.16*193.59 | EDP | / | 30PIN | 220nits IPS | ||
| 19 | RXL190071-A | 1280*1024 | 396*324*11.2 | 376.32*301.06 | LVDS | / | 30PIN | CTP | |
| 21.5 | RXL215072-A | 1920*1080 | 495.6*292.2*10.6 | 476.64*268.11 | LVDS | / | 30PIN | CTP | |
| RXL215090-A | 1920*1080 | 489.3*287*12.8 | 476.06*267.8 | LVDS | / | 30PIN | IPS |
